REAR AXLE, 4.30 RATIO

• Max road speed: 75 MPH

WORK TRUCK PREFERRED EQUIPMENT GROUP

• includes standard equipment

SPARE TIRE DELETE

• (STD)

SEATS, FRONT 40/20/40 SPLIT-BENCH, 3-PASSENGER

• driver and front passenger recline with outboard head restraints and center fold-down armrest with storage. Vinyl has fixed lumbar and cloth has manually adjustable driver lumbar. (STD)

MIRRORS, OUTSIDE HEATED POWER-ADJUSTABLE VERTICAL TRAILERING, UPPER GLASS, MANUAL-FOLDING AND EXTENDING, BLACK.

• Includes integrated turn signal indicators consisting of 51 square inch flat mirror surface positioned over a 24.5 square inch convex mirror surface with a common head and lower convex spotter glass (convex glass is not heated and not power adjustable) and addition of Auxiliary cargo lamp for backing up (helps to see trailer when backing up with a trailer) and amber auxiliary clearance lamp

DPF, DIESEL PARTICULATE FILTER, MANUAL REGENERATION

• customer regeneration will not be allowed until the DPF load percentage has reached 100% full and a driver information center (DIC) message has been shown

JET BLACK, CLOTH SEAT TRIM

• includes manually adjustable driver lumbar

AUDIO SYSTEM, 7" DIAGONAL COLOR TOUCH-SCREEN WITH CHEVROLET INFOTAINMENT

• AM/FM stereo with seek-and-scan and digital clock
• includes Bluetooth® streaming audio for music and select phones. Includes (UQ3) 6-speaker audio system.

ENGINE, DURAMAX 6.6L TURBO-DIESEL V8, B20-DIESEL COMPATIBLE

• 350 hp @ 2700 rpm
• 700 lb.-ft. torque @ 1600 rpm (STD)

RUGGED DUTY SERVICE TRANSMISSION, AUTOMATIC CLOSE-RATIO 6 SPD WITH DOUBLE OVERDRIVE, ALLISON, A2750RDS

• ratios: 3.10 1ST
• 1.80 2ND
• 1.40 3RD
• 1.00 4TH
• 0.70 5TH
• 0.61 6TH Rugged Duty Series
• includes park pawl

POWER TAKE OFF, ENGINE CONTROL PROVISIONS

• Access is available on left-hand and right-hand side

WHEELS, 19.5" X 6.75", STEEL, BLACK PAINTED, 8-HOLES, HUB PILOTED

• (STD)

TIRES, FRONT 225/70R19.5H TRACTION BLACKWALL CONTINENTAL

• Max Axle Load: 8
• 000 lb.

TIRES, REAR 225/70R19.5H TRACTION BLACKWALL CONTINENTAL

• Max Axle Load: 15
• 500 lb.

• PAINT SCHEME

• STYLE 1

  WINDOWS

• POWER WITH DRIVER EXPRESS UP AND DOWN AND EXPRESS DOWN ON ALL OTHER WINDOWS

  GVWR

• 23
• 000 LB. (10
• 433 KG)

  MIRROR CAPS

• CHROME

  WHEELBASE

• 201" (510.5 CM)
• 120" CA

  FRONT STABILIZER BAR

  FRONT AXLE

• 7
• 500 LB.
• DANA SPICER 60-256
• SINGLE-REDUCTION
• FRONT DRIVING

  REAR SUSPENSION

• 15
• 500 LB. (7
• 031 KG) MULTI-LEAF
• VARI-RATE

  DIFFERENTIAL

• HEAVY-DUTY LOCKING REAR

  SUMMIT WHITE

  REAR AXLE

• 15
• 500 LB. (7
• 031 KG)
• DANA SPICER S16-130
• SINGLE REDUCTION

  30

• 000 LB. GCWR (13
• 607 KG)

  6500 HD SERIES

  FOG LAMPS

• FRONT
• HALOGEN

  6-SPEAKER AUDIO SYSTEM

  LICENSE PLATE KIT

• FRONT

  PAINT

• SOLID
